The Mattoc Pro is the fruit of one of the most profound development cycles in Manitou history. Capable of not only pulling duty in a wide range of disciplines ranging from XC to light enduro but doing so with zero compromise makes it “best-in-class”. Maximizing weight and stiffness with a variety of tuning adjustments available makes the Mattoc Pro is an amazingly versatile product that’s capable of improving your ride. A true no-compromise authentic fork serving the real needs of MTB riders offering serious performance advantages no matter how you choose to ride.Dorado Air spring with Infinite Rate Tune (IRT) features a unique balancing valve that equalizes the positive and negative air chambers during the air fill process creating a consistent feel without any flat or dead spots in the stroke
Sealed Dampers offer more consistent damping and lighter break away force especially over long descents. The Damper uses a bladder system to compensate for head build up along with a relief valve
TSR (Trail Side Relief) casting bleed screws allow users to release casting pressure from the fork. Releasing casting pressure can improve overall fork feel and small bump compliance
Reduced weight of 59 grams from the previous model
Steerer Type | Tapered |
Color | Black w/Polished Crown |
Lockout Switch | None |
Brake Type | Post Mount 160 |
Crown Race | 40 |
Negative Spring | Air |
Weight | 1760 |
Offset | 44 |
Designed for ebike | Yes |
External Adjustments | Rebound Damping |
External Adjustments | High Speed Compression Damping |
External Adjustments | Low Speed Compression Damping |
External Adjustments | Bottom Out Resistance |
Defined Color | Black |
Positive Spring | Air |
Axle to Crown Length | 552 |
Front Axle | 15mm Thru x 110mm |
Stanchion Diameter | 34 |
Maximum Tire Width | 67 |
S.H.I.S. Stem Clamp Diameter | 28.6 |
Steerer Tube Length (mm) | 250 |
